|Machine Name||FINTEC 1107|
|Asking Price||Name Your Price!|
|Engine and Components|
|Engine Burns Oil||No|
|Engine Oil Leaks||No|
|Conveyor Belts Condition||Good|
|Engine Parts Condition||Good|
|Drivetrain and Mechanical|
|Wheels Condition||Not Applicable|
|Pumps and Motor Leaks||No|
|Hydraulic System Condition||Good|
Fintec 1107 is mounted directly onto chassis on 4 pins. This has the added benefit of eliminating stress on the chassis.
Hydraulic wedge adjustment system on CSS, Minimum CSS of 40mm on recycling applications. The Hydrostatic drive thus enabling reverse movement on crusher to clear any blockages. Maximum clearances under both crushing chamber and also along discharge conveyor for serviceability.
The feed material is directly loaded by an excavator into the feed hopper, which has a nominal volume of 7 m3 (9.2yds3). The feeder is equipped with a grizzly section located at the discharge end for removal of fines. This feature allows the passage of fine material direct to the discharge conveyors, so that it does not pass through the Jaw Crusher feed opening. This design makes possible a high production capacity by avoiding the accumulation of fine material (sometimes mud or clay) at the bottom end of the crushing chamber. The layer of fine material separated by the grizzly feeder is fed on to the main conveyor belt before the drop point from the jaw crusher and reduces the impact from the larger stones on the belt, beneath the Jaw Crusher. The fine material and the crushed product are transported on the main conveyor.
