See video
Basic Information
Machine NameFintec 1107 Jaw Crusher
Machine ID789
Model Number
Hours900
Asking Price299000
Machine Information
ManufacturerFintec
CategoryCrushers
Overall ConditionGood
Year2008
Engine and Components
Engine Burns OilNo
Engine Oil LeaksNo
Conveyor Belts ConditionExcellent
Engine Parts ConditionExcellent
Engine ConditionExcellent
Drivetrain and Mechanical
RollersExcellent
TracksYes
Tracks ConditionExcellent
WheelsNo
Wheels ConditionExcellent
Hydraulics
Pumps and Motor LeaksNo
Hose LeaksNo
Hydraulic System ConditionExcellent
Body
Physical DamageNo
Paint ConditionExcellent
Overall AppearanceExcellent

Additional Information

2008 Fintec 1107 Jaw Crusher

Only 900 Hrs  Ready to Work  Excellent Condition

Price: $299,000







The Fintec 1107 Jaw Crusher has been jointly designed by ourselves and Sandvik Rock Processing,

utilizing the very latest technology, including finite element techniques to minimize stress

levels within the frame itself. Sandvik have used all their experience gained over the last

100 years in crushing, to produce their most modern and efficient crusher, which is

targeted at the Recycling and Aggregate Contractor segment of the market.



Fintec 1107 is mounted directly onto chassis on 4 pins. This has the added benefit of

eliminating stress on the chassis. The Sandvik J11 crusher is welded in low

stress areas, thus giving longer life.



Hydraulic wedge adjustment system on CSS, Minimum CSS of 40mm on recycling applications.

The Hydrostatic drive thus enabling reverse movement on crusher to clear any blockages.

Maximum clearances under both crushing chamber and also along discharge conveyor

for serviceability.



The feed material is directly loaded by an excavator into the feed hopper, which has a

nominal volume of 7 m3 (9.2yds3). The feeder is equipped with a grizzly section

located at the discharge end for removal of fines. This feature allows the

passage of fine material direct to the discharge conveyors, so that it

does not pass through the Jaw Crusher feed opening. This design makes

possible a high production capacity by avoiding the accumulation of

fine material (sometimes mud or clay) at the bottom end of the

crushing chamber. The layer of fine material separated by the

grizzly feeder is fed on to the main conveyor belt before

the drop point from the jaw crusher and reduces the

impact from the larger stones on the belt, beneath

the Jaw Crusher. The fine material & the crushed

product are transported on the main conveyor.







Standard Features:

Robust, high strength, crushing chamber

High capacity, high reduction performance

Direct hydraulic drive with reverse movement in crusher

Wedge hydraulic adjust system for closed side setting

High level automatic stop/start feeder unit

Hydraulic folding hopper sides

CAT (350hp) engine

500mm wide tracks

Fully accessible user-friendly chassis design

Transportation Dimensions:

Width: 9' 2"

Height: 11' 2"

Length: 47' 2"

Weight: 47.6 Tons









Feed Hopper:

The Feed hopper has a nominal volume of 7m3 and

the hopper has hydraulic foldable sidewalls, for ease

of transportation. The hydraulic system enables the

operator to control the feed rate, by changing the

speed of the vibration motor. This feature is especially

useful in order to obtain maximum output from the

whole installation; also an ultrasonic level system will

automatically start & stop of feeder depending on the

level of material above the crusher.





Volume: 9.2Yd3

Width: 8' 2"

Length: 14' 7"

Material: 1/2"

Hydraulic Cylinders: 3

Structure Foldable fixing w/support legs









Feeder:



The feeder is a vibrating grizzly unit (4.2m x 1.04m) including 1600 mm long grizzly section.

This feeder has been specially designed for operation with coarse material and high impact

load. The feeder has cassette type grizzly bars and is fitted with Hardox 400 liner

plates. This feeder has two unbalanced shafts located under the vibrating

structure. They rotate in opposite directions, resulting in

straight-line motion due to the self-synchronizing effect.

The vibrators are oil lubricated and have adjustable

counterweights.





Width: 3' 5"

Length: 13' 8"

# of Grizzlies: 2

Grizzly Length: 5' 3"

Grizzly Space Option: 1 1/2" to 2"





Crusher:



Feed Opening: 44"x28"

Minimum CSS Recycling: 1 1/2"

Minimum CSS Rock: 3"

Length of Fixed Jaw: 4' 7"

Speed: 270 RPM

Adjustment System: Hydraulic Wedge

Drive: Hydraulic





Swing and Stationary Jaw Plates:

These are cast of austenitic manganese steel, with various

profiles, specific for each material to be crushed. The

dimensions are the same for the stationary and the moving

jaw plates. This makes it possible to freely change the

position of the jaw plates. The jaw plates are fixed to the

crusher's swing jaw and frame by means of wedges and tie

bars.



Swing Jaw:

This is a heavily ribbed one piece steel casting. Its eccentric

movement (throw) causes the jaw plates to crush the material

as it is forced down trough the crushing chamber.





Shaft:

The eccentric shaft for the J11 crushers is a low-alloy steel

forging. The eccentric part of the shaft provides the throw

of the swing jaw. Precision machined and of ample diameter, it

ensures that the bearings have a long useful service life. For

extra heavy duty service the roller bearings are of the

self-aligning type, protected by labyrinth seals and

are grease lubricated.







Cheek Plates (Side Liners):



These plates are made of austenitic manganese steel, and

protect the frame against abrasive wear in the region of the

crushing chamber. They are bolted to the crusher side plates.

Note that the left and right hand cheek plates are identical,

and thus reduce the number of different spare part items that

have to be stocked.



Toggle Plate and Seat:

This is a nodular iron casting. Its ends rest in the "lubrication-free rolling-contact"

toggle seats, thus maintaining the lower part of the swing jaw in the correct

position. It takes up most of the compression force generated in the

crushing chamber by the swinging movement of the swing jaw. The

wear parts of the toggle seat, which support the toggle plate,

are made of medium carbon steel, and machined in order to

ensure the correct dry rolling contact.







Setting Adjustment:



Fully hydraulic adjustment, wedge type.

1 ½” – 5”    CSS

3” – 7”      CSS

The 2 different CCS setting ranges are

obtained by changing toggle plates.







Flywheels:



Made of cast steel, their geometry provides a high moment of inertia, thus reducing the dynamic load variations transmitted to the motor. They are fixed to the shaft in a manner that facilitates disassembly, even after a long time in service. Each flywheel is also fitted, with a counter-weight that balances the crusher in the best way possible, reducing horizontal forces to a minimum.







Crusher Load Sensing:



a) Ultrasonic level system, above crusher, controls the feed from the feeder into the

crusher to obtain constant material flow and maximum output.



b) Speed sensor on drive flywheel, observes

crusher speed, max 270 rpm and min 235 rpm,

to control crusher feed and avoid overloading of

crusher unit.







Conveyor & Crusher Outlet:



The discharge belt conveyor is with the tail section fitted

underneath the jaw crusher and crusher by-pass chute.

To give maximum ground clearance the tail section of the

conveyor is automatically lowered or raised into different

positions, depending on if the unit will be crushing or

crawling. The ground clearance underneath the unit is

260mm (raised). The drive drum is fitted with rubber to

prevent the belt from slipping. Rubber Impact bars is

placed in the drop zone underneath the jaw crusher. The

discharge height of the main conveyor is 3300mm. The

conveyor has a low position sensor, this stops the crusher

being tracked when conveyor is in its lowest position and

therefore damage to the conveyor belt.





Width: 40"

Length: 37' 1"

Discharge Height: 10' 11"

Belt Thickness Material: EP500/3ply 8+2 Grade X

Tail Drum Diameter: ø273mm

Head Drum Diameter: ø290mm

Distance between Jaw & Belt: 2'

Impact Area: Yes

Access to space Crusher / Conveyor: Excellent



Engine / Transmission:

C9 turbo-charged, intercooler six cylinder, diesel engine power pack developing 262 Kw

(350 Hp) is available. The engine meets the EU Emission Regulation 97/68/EC step II.





Engine kW/hp: CAT 350Hp

Crusher Drive: Sauer Danfoss

Pumps: Sauer Danfoss

Hydraulic Motors: Sauer Danfoss / Eaton

Hydraulic Valves: Sauer Danfoss

Fuel / Hydraulic Tank: 132 gal







Frame:

Rigid one piece welded construction consisting of steel plates and cast carbon steel parts,

heat-treated after welding (for internal stress relief), and then precision machined.

The simultaneous use of both plate and castings makes it possible to position the

weldments in regions of lower mechanical stress. This feature considerably

increases the fatigue resistance of the welded frame assembly.





Steel Structure / Tacks:



The Crawler tracks have a length of

3850 mm and track shoe width is 500

mm. The normal ground pressure is

129 KPa together with a travelling

speed of 1.2 km/h. Hydraulic motor.





Frame Material: Steel Frame & Cast Carbon Steel Parts

Frame Description: Rigid One Piece Welded Structure

Track Shoe Width: 20"

Track Length C-C: 12' 6"

Track Manufacture: Strickland / Trackline



Options:

Wheel Bogie: Yes

Working Lights: Yes

Side Conveyor: Yes

Dust Encapsulation Covers: Yes

Belt Protection Plate Under Jaw: Yes

Water Dust Suppression (no pumps): Yes

Hardox Wear Plate For Hopper: Yes

Hydraulic Hammer: Yes

Artic Climate Pack (-20 C): Yes

Magnetic Separator: Yes

Weigh Scales: Yes



Control System:

Control System: Automotive Control

Control From Platform: Yes

Emergency Stops: Yes x 6

Radio: Yes
